暗箱式光強度量測系統 LID-060
TYPE C GONIOPHOTOMETER
Fixed vertical axis, moving horizontal axis. Measurements are performed in the C-plane or on conical surfaces. Type C corresponds to type B, if the light source is rotated by 90°.
LID-060 Goniophotometer & Goniophotometer
LID-060 can perform CIE type C-γ measurement solution which is most widely applied in industrial factory. With an angular resolution of 0.01º the goinophotometers capture highly accurate and excellent spectrometer LED measurements.
The software controls the measurement process and the power supply / electrical measurement of the sample. Switch-on and stabilization routines are configurable and storable and can be conveniently retrieved for repetitive measuring tasks.
1. Precise determination of luminous intensity distribution and luminous flux
2. Angle-dependent analysis of spectral and colorimetric quantities
3. In conformity with the C, ɣ coordinate system and international measurement standards
(CIE S025/ EN13032-4)
4. Unique combination of a fast photometer and the world-wide recognized reference spectroradiometer CAS 140D
Measurement Parameters
Measured parameters include luminous intensity distribution curve, arbitrary
cross-section of luminous distribution curve, candela distribution curve, bright limit curve, zonal luminous flux, luminaires efficiency, total luminous intensity, luminous flux, and utilization factor.
